Combination filter 80 Ast (Class A2P2 R D)
The combination filter 80 ASt is designed for use in areas contaminated by dusts and solvent vapours. The design guarantees the filtration of organic gases and vapours (boiling point > 65°C) and a particle filtration efficiency > 94.95%.
It is a screw filter according to EN 14387-A2-P2 RD, with standard thread connection according to EN 148-1, against organic gases and vapours with a boiling point above 65°C and simultaneously occurring particles of low-toxic substances. All sites of operation can be found in the primary areas of use.
Individually shrink-wrapped in PE bags and packed in a carton. Weight: approx. 225g.
| Application focus: | Painting, solvent vapors with boiling point > 65 ° C, organic solvent vapors, paint stripper, rock dust, glass wool, mineral fibers, wood dust, soot, steel dust, herbicides and pesticides (low-toxic), bacteria and viruses |
|---|---|
| EN standard: | DIN EN 133, DIN EN 148-1, DIN EN 14387:2008 |
| Filter section: | A – Vapors of organic compounds with boiling point > 65 ° C | P – Particles |
| Filter type: | Combination filter |
| Material: | Aluminium |
| Product category: | Respiratory filter |
| Product series: | Screw filter |
| Version: | Combination filter |
Login
| File | Category | Size | Filetype | Prio |
|---|---|---|---|---|
| Brochure Respiratory filters | Product informations | 1.62 MB | ||
| 924300-Datasheet-Breathing-Filter_80ASt | Datasheets | 186.01 KB | ||
| 07_EU-type-examination_Filter_80 | EU type-examination certificates | 1.14 MB | ||
| 07_EU-Declaration-of-conformity_Combination-filter_80_81_84_85_86 | EU declarations of conformity | 514.28 KB |
Accessory
