Particulate matter analyser DustLight MINI
The Dustlight is a hand-held particulate matter analyser for use in trade and industry. It measures respirable dust, the PM10 fraction of inhalable dust, as well as PM1 and PM2.5. The Dustlight has illuminated areas that are clearly visible from all sides and change colour when critical values are exceeded. This is based on the workplace limit values from TRGS 900, specifically the general dust limit for respirable dust. The illuminated areas change colour from yellow to red when the dust concentration exceeds the general dust limit value of 1250 μg/m³. The threshold for changing from green to yellow can be configured via the app the default setting is 10% of the dust limit value.
Technical features:
- Measured variables: PM1, PM2.5, PM10, A-dust Patent-pending measuring principle to prevent clogging of the optical sensors
- App connection to display history, limit value setting and data export data export
- Anti-dust charging socket Patented Klick Fast system with over 20 different clips and fastening options
- Display to show the current A-dust load
- Battery life up to 40h
- Dimensions: 69 x 69 x 32.2 mm without clip (LxWxH)
- Weight: 149 g
Scope of delivery:
- Dustlight dust meter
- Magnetic USB charging cable
- Quick guide
Attention, a USB power supply is not included!
Various accessories are available for the DustLight MINI. Please feel free to contact us!
Login
| File | Category | Size | Filetype | Prio |
|---|---|---|---|---|
| 203088_Maintenance DustLight MINI | Service documents | 235.60 KB | ||
| 203088-Data-sheet-DustLight-MINI | Datasheets | 436.29 KB |
